Grade by Grade
A. Global Settlement: Patterns and Sustainability · Global Settlement: Patterns and Sustainability

Designing a Sustainable Community of the Future

A1.3 A2.6About 50 minutes
Learning goals
  • I can describe possible features of a sustainable community of the future.
  • I can analyse challenges in creating such a community, such as cost, population growth, urbanization and dependence on fossil fuels.
  • I can suggest ways to overcome those challenges.
  • I can design and present a sustainable community plan for a specific audience.

Words to know

complete community
A community where people can meet most daily needs (homes, jobs, shopping, school, parks, health care) close by, often within a short walk, bike ride or transit trip.
mixed-use
Combining different land uses in one area or building, such as apartments above stores.
net-zero building
A building that produces as much energy as it uses over a year, or offsets what it uses.
energy-efficient
Using less energy to do the same job, for example through good insulation or efficient heating.
native species
Plants and animals that naturally belong in a region.
fossil fuels
Coal, oil and natural gas, formed from ancient living things. Burning them releases greenhouse gases.
audience
The people who will read, hear or see your work. Good communication is chosen for its audience.

Let's imagine

It's the year 2050. You're about 37 years old. You walk out of your apartment, which stays warm in winter with very little energy. A tram stops at the corner. Your neighbours are picking tomatoes in a rooftop garden. Kids are cycling safely to school on a protected path. Rainwater from the streets flows into a pond full of frogs instead of a storm sewer.

Is that community possible? What would it take? In this lesson you'll describe features of a sustainable community of the future and analyse the challenges of building one.

A rooftop vegetable garden with tomato plants in raised beds, with a tram passing on the street below.
Rooftop gardens and trams are two features of a sustainable community. What other features would you include in your community of 2050? AI-generated image

Possible features of a sustainable community

Buildings and energy

  • Energy-efficient and net-zero buildings with thick insulation, good windows and efficient heat pumps.
  • Renewable energy: solar panels, wind, geothermal or biomass heating.

Getting around

  • Comprehensive public transit: frequent buses, light rail or subways that connect to everything.
  • Safe sidewalks and protected bike lanes, kept clear in winter.
  • A complete community design: homes, shops, schools, health care and parks close together, often in mixed-use buildings.

Nature and food

  • A green canopy of street trees, and parks with native species that support birds and pollinators.
  • Community gardens and rooftop gardens for local food.
  • Stormwater ponds, rain gardens and green roofs that handle rain naturally.

Water and waste

  • Water recycling (greywater reuse) and water-saving fixtures.
  • Waste recycling and composting, with less waste made in the first place.

People

  • Affordable homes of different sizes for different families.
  • Accessible design for people who use wheelchairs, walkers or strollers, and for older adults.
  • Places to gather, and a real say for residents in decisions.
homes above shopspark, native plantstransit line with stopscommunity gardenpondschool, clinicpretend plan view, not to scale
A plan view of a pretend sustainable neighbourhood: homes above shops on one side of a transit line, a park with native plants on the other, and a community garden, a stormwater pond, and a school and clinic within walking distance of the transit stops. Not to scale.

Real examples to learn from

  • Drake Landing Solar Community in Okotoks, Alberta, collects heat from the sun with solar collectors on garage roofs in summer, stores it underground, and uses it to heat homes in winter. It shows that solar heating can work even in a cold Canadian climate.
  • Many First Nations across Canada own or co-own solar, wind and hydroelectric projects. These projects provide clean energy and income, and in some remote communities they reduce the need for diesel fuel that has to be flown or shipped in.
  • Växjö, Sweden (from the last lesson) heats much of the city with renewable wood waste.
garageSUMMERsolar collectors ongarage roofs catch heatheat storedundergroundsummer:heat goes downwinter:heat comes backhomeWINTERstored heat warmsthe homesDrake Landing, Okotoks, Alberta: schematic, not to scale
Drake Landing's trick: catch the sun's heat in summer, store it underground, and use it to heat homes in winter.

Challenges

Building a sustainable community is not easy. Some of the biggest challenges are:

  • Cost. Transit lines, net-zero buildings and renewable energy cost a lot to build, even if they save money over time.
  • Population growth and urbanization. Cities must house many new people quickly, and fast building can lead to sprawl.
  • Dependence on fossil fuels. Many homes are heated with natural gas, many vehicles burn gasoline, and changing over takes time and money.
  • What is already built. Many communities were designed around cars, with homes far from stores and jobs. Rebuilding takes decades.
  • Climate. Canada's cold winters mean a lot of energy is needed for heat, and paths must be cleared of snow.
  • Habits and choices. People may be used to driving and may resist change.
  • Fairness. New "green" neighbourhoods can become expensive, pushing out people with lower incomes, unless affordable housing is included.
  • Competing interests. Different groups want different things from the same land (as you saw in the land-use lesson).
Worked example

Example: Let's analyse a feature and its challenges

A town council proposes: "All new homes must be net-zero by 2035." Analyse this feature: its benefits, its challenges and a possible solution.

  1. Benefit (environmental): net-zero homes cut greenhouse gas emissions from heating and electricity.
  2. Benefit (economic): families pay lower energy bills over the life of the home.
  3. Challenge: net-zero homes usually cost more to build, which could make housing less affordable at a time when the population is growing.
  4. Challenge: builders need training and suppliers need the right materials.
  5. Possible solution: offer grants or loans for the extra cost, phase the rule in, and train local builders.

Net-zero homes have clear environmental and economic benefits, but cost and skills are challenges. A gradual rule with financial support and training could make it work.

Communicating for an audience

When you present your plan, think about who you are talking to. A town council wants costs, benefits and evidence. Younger students want pictures and simple words. Residents want to know how it affects their daily lives. Choose your format (a labelled map, a slideshow, a model, a short video or a letter) to fit your audience, and use geography vocabulary such as density, land use and sustainability.

Hands-on activity

Design a sustainable community

You need: a large sheet of paper, a pencil, a ruler and coloured pencils (or building blocks or recycled boxes for a 3-D model).

  1. Choose a real or pretend place in Canada and note its climate and physical features (river, hills, lake).
  2. Draw a plan view with a title, legend, compass rose and a note saying "not to scale". Include at least six sustainable features from this lesson, including transit, homes, green space, energy and water.
  3. Next to your map, list three challenges your community would face and one solution for each.
  4. Choose an audience (town council, Grade 3 students or residents) and prepare a 2-minute pitch for them. Present it to your family.

What to look for: features that fit the place's climate and landforms, a clear legend, realistic challenges with solutions, and language suited to the chosen audience.

Just for fun

Future you, age 37: "Back in my day, we burned squished ancient swamp plants to drive 5 km for one bag of chips." Future kid: "Why didn't you just walk to the corner store in your complete community?"

Your turn

1

List five possible features of a sustainable community of the future.

2

What is a complete community?

3

Name four challenges of creating a sustainable community.

4

How does Drake Landing Solar Community in Okotoks heat homes in winter?

5

Why are renewable energy projects especially helpful for some remote First Nations communities?

6

Why might a new "green" neighbourhood become unfair?

7

What should you think about first when choosing how to present your plan?

More practice: warm-up

1

What does mixed-use mean?

2

What is a net-zero building?

3

What are native species?

4

Name one fossil fuel.

5

Give one reason community gardens make a community more sustainable.

More practice: on your own

1

Explain how a complete community reduces greenhouse gas emissions.

2

Why is Canada's climate both a challenge and a reason to build energy-efficient homes?

3

Explain why rebuilding a car-based suburb into a complete community takes a long time.

4

Choose an audience (town council or Grade 3 class) and describe how you would present a plan for a green roof to them.

5

How does population growth make sustainability harder?

Challenge

1

A city has two choices for the same money: (A) a new highway lane, or (B) a frequent bus rapid-transit line. Analyse which better supports a sustainable future, using environmental, social and economic reasons.

2

"Dependence on fossil fuels" is a challenge. Suggest three steps a community could take to reduce it, and one difficulty for each.

3

Design question: In a sustainable community in Nunavut, which features from this lesson would work well, and which would need to change? Explain using the physical environment.

Check your understanding

Quiz

1.

Which is a feature of a sustainable community?

2.

What is a complete community?

3.

Which is a challenge to building sustainable communities?

4.

What does Drake Landing Solar Community show?

5.

Why might a new green neighbourhood push out lower-income people?

6.

When presenting a plan to a town council, what is most useful to include?

For parents and teachers

Big idea: A1.3 asks students to describe possible features of a sustainable community in the future and analyse some challenges associated with creating such a community. The curriculum's examples of features include energy-efficient buildings, renewable energy, comprehensive public transit, community and roof gardens, a green canopy, native-species parks and waste and water recycling; its examples of challenges include cost, population growth, urbanization and dependence on fossil fuels. The design-and-pitch activity also practises A2.6 (communicating for a specific audience).

Common difficulties:

  • Dream plans with no challenges. Ask, "What would make this hard? Who pays?"
  • One-size-fits-all designs. Features should suit the place's climate and landforms (see the Nunavut challenge question).
  • Forgetting people. Remind your child about affordability and accessibility.

How to help: Be the "town council" for your child's pitch and ask friendly, tough questions about cost and fairness. A walk or drive through a newer and an older neighbourhood can spark ideas about what makes a place walkable.
